Hydraulic Oil Presses for Brake Powder Forming

Hydraulic Oil Presses for Brake Powder Forming

    Payment Type: L/C,T/T
    Terms of Trade: FOB,CIF
    Min. Order: 1 Set/Sets
    Delivery Time: 90 Days
    Packaging: Standard International Wooden Case or Iron Pallet
    Productivity: 200set/Yeat
    Brand: ZHENGXI
    Transportation: Ocean
    Place of Origin:  China
    Supply Ability: 200set/Yeat
    Certificate: ISO9001, CE
    HS Code: 8462919000
    Port: CHONGQING,SHANGHAI

Basic Info

Model No.:  Yz79

Product Description

Hydraulic Oil Presses for Brake Lining Powder Forming

In the entire automotive industry, the brake (brake) piece is a very important and indispensable part. If it is lacking, the safety of the car on the road will not be guaranteed. Moreover, the product is both a safety piece and a fragile item.

Brake Pads can be divided into asbestos sheets, semi-metal sheets, and NAO (non-asbestos organic) sheets, depending on the material being manufactured. According to different braking methods, the brake pads can be divided into two types: disc brake pads and drum brake pads.

The first generation: asbestos brake pads: 40% - 60% of its composition is asbestos.

Second generation: semi-metallic mixture brake pads: mainly using coarse steel wool as a reinforcing fiber and an important mixture.

The third generation: non-asbestos organic NAO brake pads: mainly used glass fiber, aramid fiber or other fibers (carbon, ceramics, etc.) as a reinforcement material.

Truck drum production line process: Mixing→Cold pressing→heat treatment→grinding arc→grinding end face→grinding angle→drilling→cleaning→quality inspection→printing→packaging→instock

Car disc brake pad production process: Mixing→steel blanking→fine punching→gluing→weighing hot pressing/cold pressing→heat treatment→grinding plane→grooving→surface high temperature treatment→painting→quality inspection→marking→packaging→instock

Features

1.The frame is heavy-duty as well as compact and it assures precise results.It is made of high quality mild steel and it has undergone systematicmechanical processes.

2. Electric welding of high precision

3. Usage of high-tech boring machines for extreme precision parts

4. The composite series has been designed for applications in which structural rigidity and lexibility in terms of production are the particular rerogatives required. Machines with several actions from the top or bottom or pecial solutions enable complex shapes and large dimensions to be achieved in a number of different industries.

5. It is convenient to clean and change oil.

6. Factory full set of solution

Parameters

Mold unit 63T 100T 160T 200T 250T 315T 500T 630T 800T 1000T 1250T
Main cylinder (slider) process specs Max.press force KN 630 1000 1600 2000 2500 3150 5000 6300 8000 10000 30000
Max.return force KN 150 100 315 450 540 630 1000 1000 1200 1600 2100
Down speed mm/s 100 100 160 160 140 140 140 250 200 150 150
Slow speed mm/s 20 15 15 15 12 15 15 15 15 15 12
The proportion of floating pressing speed mm/s 20.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00
Press speed mm/s 10 10 10 10 7 8 8 8 8 8 6
Return speed mm/s 120 120 120 110 95 100 100 150 150 120 120
Max.stroke mm 400 500 500 500 500 500 600 600 600 600 600
Top cylinder process specs Max.ejection force KN 280 440 450 900 900 1250 1800 2200 2200 2750 10000
Max.pull force KN 280 360 450 750 750 1250 1800 2200 2200 2750 2750
Max.stroke mm 150 150 150 150 150 150 150 150 150 150 150
Eject speed mm/s 80 34 65 55 50 50 50 60 60 60 60
Floating speed mm/s 20.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00 15.00
Return speed mm/s 80 42 95 70 70 50 50 60 60 60 60
Upper center cylinder process specs Max.press force KN 60 60 60 125 150 125 200 200 240 240 500
Max.return force KN 30 30 30 76 76 76 130 130 140 140 200
Max.stroke mm 30 30 30 45 45 45 50 50 50 50 50
Under center cylinder process specs Max.press force KN 70 70 125 160 160 200 200 300 300 300 1000
Max.return force KN 40 40 75 100 100 100 100 200 200 200 260
Max.stroke mm 150 150 150 150 150 150 150 150 150 150 150
Upper floating cylinder process Max.press force KN 120 120 130 250 250 300 400 400 480 480 1000
Max.return force KN 60 60 65 150 150 160 200 200 240 240 250
Max.stroke mm 45 45 50 60 60 70 70 70 70 70 70
Effective worktable size L-R mm 580 720 780 1000 1000 1000 1200 1320 1400 1600 2400
F-B mm 490 580 640 940 940 960 1140 1200 1200 1350 1460
Max.pressure of liquid mpa 25 25 25 25 25 25 25 25 25 25 25
Max.filling height mm 120 120 120 120 120 120 120 120 120 120 120
Main motor power KW 7.5 11.5 18.5 22 22 30 48 67 82 100 100

Certificate

hydraulic-press-machine-factory-details
hydraulic-press-machine-application
Hydraulic Oil Presses for Brake Powder Forming

Certificate

Hydraulic Oil Presses for Brake Powder Forming

AFTER-SALE

1.Personnel training
Free training for about one week.

2. After-sale service
One year warranty.During warranty period,free maintenance service can be provided.(except man-made faults or damages arising from irresistible natural factors)

3.Installation
Customers need to pay the commission to our proffessional engineer, and travel expense is on foreign customer.(Including round ticket and accommodation cost)

Our company is an ISO 9001 certified Company, and as an approved supplier for the automotive sector, has also received the CE certificates .

CHENGDU ZHENGXI HYDRAULIC EQUIPMENT MANUFACTURING CO., LTD.



Chengdu zhengxi hydraulic equipment manufacturing company located in Chengdu North Economic Development Zone, is engaged in hydraulic machinery and hydraulic system of R & D, manufacturing and sales in one of the professional manufacturers.

H-fram-hydraulic-press-machine

The main products are hydraulic machine, anti-theft door embossing machine, single column hydraulic machine, sealing machine, vulcanizing machine, three machine, the largest tonnage of 3150 tons can be single cylinder. At the same time, for the different needs of customers design and production of non-standard hydraulic equipment.

hydraulic press machine made in china

The company products are mainly characterized by generous appearance appearance, simple operation, convenient repair. In product quality, we maximize the use of national and industry standard design, strictly grasp every process, to ensure that every part quality. A hydraulic press is a machine that uses liquid as a working medium to transfer energy to achieve various processes. In addition to forging forming, hydraulic presses can also be used for correction, press fitting, packing, briquetting and pressing. The hydraulic press includes a hydraulic press and a hydraulic press. A water-based liquid is used as a working medium, which is called a hydraulic press, and an oil as a working medium is called a hydraulic press. The specifications of hydraulic presses are generally expressed in terms of nominal working force (kilograms) or nominal tonnage (tons). The hydraulic press for forging is mostly a hydraulic press with a high tonnage. In order to reduce the size of the equipment, large forging hydraulic presses usually use higher pressure (about 35 MPa), and sometimes use ultra high pressure of 100 MPa or more. Hydraulic presses for other purposes generally use a working pressure of 6 to 25 MPa. The hydraulic press has a lower tonnage than a hydraulic press.

hydraulic_press_manufacturer

The company continued to introduce, digest, absorb foreign advanced equipment and technical characteristics into the products, leading product Yz32 series four-pillar hydraulic machine and Yz41 series single column hydraulic press has been in the same industry in a leading position at home and abroad, well received by customers welcome.
